    40 - 50 Tons Side Dump Semi Trailer , 35 Cbm Heavy Duty Commercial Dump Trailers

    Ask Lasest Price
    Brand Name : SINOHTC
    Model Number : HTC9401UBGZX
    Certification : ISO9001
    Price : Negotiation
    Supply Ability : 50 UNITS PER MONTH
    Delivery Time : 30 DAYS
    Payment Terms : L/C, T/T, Western Union, MoneyGram, MoneyGram
    • Product Details
    • Company Profile

    40 - 50 Tons Side Dump Semi Trailer , 35 Cbm Heavy Duty Commercial Dump Trailers

    40- 50tons U shape Dump trailer / self dumping trailer/ heavy duty dump trailer 35 cbm dump body


    Specifications:


    DIMENSIONS8600*2500*3300MM
    INNER DIMENSIONS7690*2330*1420MM
    TARE WEIGHTwithin 8.3T
    PAYLOAD35-45T
    Photo for reference, final product can be manufactured according to exact requirements
    DUMPER BODY
    FLOOR6MM
    SIDE/FRONT/REAR PLATE4MM (T750 high tensile)
    VOLUMN25CBM
    SPECIFICATIONS
    ChasisHeavy duty and extra durability designed ; Opting for high tensile steel T750L, welded by automatic Submerged-Arc processes. Top Flange 14mm,width 150mm; Double Middle Flange 6mm and 8mm ; Bottom Flange 14mm,width 150mm.
    Hydraulic SystemOne set of HYVA cylinder FE-191-5-06180
    Axle3 units of L1 13T 10 holes
    Tyre13 units of DOUBLE COIN (brand) 12.00R20 (Including one spare tyre)
    Wheel Rim13 units of 8.5-20
    King Pin2'' bolted style
    Landing GearFW 19'
    SuspensionAmerican design mechanical suspension
    Leaf Spring6 sets of 7-pieces 90*16mm leaf spring
    Braking System2 of WABCO RE-6 relay valve; 6 of T30/30 Spring brake chamber; 40L air tanks
    ElectricInternational standard 24v circuit 7-pin ISO socket(JAEGER POWAY) ; Tail lamp with LED lights.
    PaintingComplete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint
    AccessoriesOne standard tool box

    Advanced production lines

    Integrated with the production , scientific researching and development, Helloo trailer insist on providing customers good quality products, like low bed trailer, flatbed trailer, fuel tanker trailer, bulk cement trailers and others 40 models trailers.


    1) Reinforced main beam and side beam to ensure high loading.
    2) Adopting China made best brand FUWA axle, Triangle tyres
    3) Good quality carbon steel is used for tank box;
